USB

General Specification :

Rating:

• Voltage: 30V AC(rms)
• Current: 1A maximum per contact not to exceed 30°C temperature rise
• Temperature: -40°C to 60°C storage; 0°C to 40°C operating

Electrical:

• Termination resistance: 30mΩmaximum
• Insulation resistance: 1000MΩminimum
• Dielectric withstanding voltage: 750V AC at sea level
• Capacitance: 2pF maximum

Mechanical:

Full line of Universal Series Bus plugs and receptacles for ease of design.
Series A and B plugs and receptacle.
SMT and Thru-hole terminals for Board Mount receptacles and plugs.
Single and Double stack for Series A receptacle.
Solder Series for A and B plugs.
Allow the connection of up to 127 devices.
Middle mount for NB market
Provides speeds of:
1.5 Mbps (USB1.0)
12 Mbps  (USB1.1)
480Mbps(USB2.0)

General Specification :
Connect resistance: 30mΩmaximum
Insulation resistance: 1000MΩminimum

General Specification :

Rating:

• Voltage: 30V AC(rms)
• Current: 1.5A PWR/GND pins
• Temperature: -40°C to 60°C storage; 0°C to 40°C operating

Electrical:

• Termination resistance: 30mΩmaximum
• Insulation resistance: 1000MΩminimum
• Dielectric withstanding voltage: 750V AC at sea level
• Capacitance: 2pF maximum

Mechanical:

General Specification :
Rating:

• Voltage: 30V AC(rms)
• Current: 1.5A PWR/GND pins
• Temperature: -40°C to 60°C storage; 0°C to 40°C operating

Electrical:

• Termination resistance: 30mΩmaximum
• Insulation resistance: 1000MΩminimum
• Dielectric withstanding voltage: 750V AC at sea level
• Capacitance: 2pF maximum

Mechanical:

General Specification :

Rating:

• Voltage: 30V AC(rms)
• Current: 1.5A PWR/GND pins
• Temperature: -40°C to 60°C storage; 0°C to 40°C operating

Electrical:

• Termination resistance: 30mΩmaximum
• Insulation resistance: 1000MΩminimum
• Dielectric withstanding voltage: 750V AC at sea level
• Capacitance: 2pF maximum

Mechanical:
